CNC ROUTER - SPARTAN 1325

1,800.00 EUR

Status: Available

SPARTAN Features

Spindle Spec - 4.5KW ATC Spindle ISO30 220V CNC Router Air Cool Automatic Tool Change Spindle Motor, 24000 rpm, 9amps, 800Hz, ISO30

Mechanical Drive - TBI ball screw on Z, helical rack & pinion on X & Y

Drive system - High-performance stepper drives

Control System - NK105 DSP control with pendant USB input hand controller

Vacuum Table - Matrix vacuum holding system - with t-slot holding clamps

Working Area - 1300 x 2500mm

Resolution Accuracy - 0.01/100mm

Gantry Height - 180mm

Fixturing - 4-Zone Vacuum Bed and T-Slot Table

Material that can be cut on the Spartan

Hard and Softwood Plywoods – variety of veneers/laminates available

Medium Density Fibreboard (MDF) – standard, fireboard and exterior-use variants

Oriented Strand Board (OSB)

Aluminium Composite Panel e.g. DiBond® – variety of finishes and colours available

Aluminium 1050 Sheet

Acrylic (Cast and Extruded) – variety of finishes and colours

Polycarbonate – variety of finishes and colours

And more!

PC Specs

Model

Dell OptiPlex 390 SFF

Form factor

Small

CPU options
